Speedmaster®
Electronic Fuel Injection Billet EFI Command Centre 2
Product Information
Overview
The Speedmaster Billet Command Centre sump kit uses the stock low-pressure, manual or EFI pump, to feed its sump tankâÃîdelivering enough fuel to power up to 800 HP engines. The pump is submerged in fuel, allowing it to run cooler and quieter than external units. The sump tank is generally mounted in the engine compartment, but it can be attached on the vehicle's chassis, if needed.
Specs
| Brand: | Speedmaster |
| Part Number: | PCE145.1043 |
| Part Type: | Fuel Pump, Electric External |
| Free Flow Rate: | 90 gah |
| Maximum Pressure (psi): | 90 psi |
| Fuel Pressure Regulator Included: | No |
| Sending Unit Included: | No |
| Vent Included: | No |
| Inlet Quantity: | One |
| Inlet Attachment: | Male threads |
| Inlet Size: | -6AN |
| Outlet Quantity: | One |
| Outlet Attachment: | Male threads |
| Outlet Size: | -6AN |
| Return Quantity: | One |
| Return Attachment: | Male threads |
| Return Size: | -6AN |
| Sump Material: | Billet Aluminum |
| Quantity: | Sold Individually |
| Notes: | Pump requires a pulse width modulation (PWM) signal to reduce heat and extend the life under low load situations where additional fuel is not needed. |
Description
A low fuel level in the fuel tank will not result in pump starvation when vehicle is on a steep incline.
Warranty Information
12-Month Limited Worldwide Warranty
Prop 65 Warning
This product may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
