Speedmaster®
PCE249.1011
Promo
Product Information
Overview
Speedmaster camshafts are built to take advantage of the latest cam technology, to provide maximum performance. Whether your use is off-roading, towing, or street performance, there is a Speedmaster cam available for you. By using an aggressive lobe profile, these cams provide better throttle response and more top-end horsepower than equivalent cams from other manufacturers, while delivering increased engine vacuum.
Specs
| Brand: | Speedmaster |
| Part Number: | PCE249.1011 |
| Part Type: | Camshaft |
| Cam Style: | Hydraulic roller tappet |
| Basic Operating RPM Range: | 1,600-5,400 |
| Intake Duration at 050 inch Lift: | 218 |
| Exhaust Duration at 050 inch Lift: | 224 |
| Duration at 050 inch Lift: | 218 int./224 exh. |
| Advertised Intake Duration: | 270 |
| Advertised Exhaust Duration: | 276 |
| Advertised Duration: | 270 int./276 exh. |
| Intake Valve Lift with Factory Rocker Arm Ratio: | 0.495 in. |
| Exhaust Valve Lift with Factory Rocker Arm Ratio: | 0.502 in. |
| Valve Lift with Factory Rocker Arm Ratio: | 0.495 int./0.502 exh. |
| Lobe Separation (degrees): | 110 |
| Computer-Controlled Compatible: | No |
| Valve Springs Required: | Yes |
| Quantity: | Sold individually. |
| Notes: | Designed for early non-roller blocks. Requires thrust button and wear plate. |
Attachments
Warranty Information
12-Month Limited Worldwide Warranty
Prop 65 Warning
This product may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
