Speedmaster®
160 Gph @ 7 PSI With Int. Reg Universal Electric Fuel Pump
Product Information
Overview
These Speedmaster electric fuel pumps are ideal for high performance street or race applications. They have a high-quality, permanent-magnet 12 V electric motor and feature factory-set base pressure. Intended for gasoline use, each pump assembly features a quiet, high-efficiency Gerotor design that provides stable output. The housings are fully machined and have a special design that allows for some adjustment of the output pressure.
Specs
| Brand: | Speedmaster |
| Part Number: | PCE145.1018 |
| Part Type: | Fuel Pump, Electric External |
| Free Flow Rate: | 160 gph |
| Maximum Pressure (psi): | 7 psi |
| Inlet Quantity: | One |
| Inlet Attachment: | Female threads |
| Inlet Size: | 3/8 in. NPT |
| Outlet Quantity: | One |
| Outlet Attachment: | Female threads |
| Outlet Size: | 3/8 in. NPT |
| Fittings Included: | No |
| Quantity: | Sold individually. |
| Notes: | Draws 9.5 amps. Bypass fitting is -8 AN with female threads. |
Warranty Information
12-Month Limited Worldwide Warranty
